Midrange External Array Mockup

This mockup shows an example of a midrange, iSCSI, external storage system. It shows a small number of instantiated volumes, storage pools, and demonstrates the use of storage groups for mapping and masking. It shows the system directly instantiated in the Storage Collection at the Service Root.

Midrange External Array with Replication Mockup

This mockup shows an example of a midrange, iSCSI, external storage system with replication.

In addition to the configuration shown in the "Midrange External Mockup", it adds replication in the form of snapshots, and demonstrates the use of consistency groups, and the additional use of storage groups specifically related to replica sets.

Direct-Attach Storage Mockup

This mockup shows an example of a small direct attach configuration, where the storage is attached to a computer system, such as a RAID controller plugged into a server. It shows a small number of instantiated volumes, storage pools, demonstrating a minimal Swordfish configuration in this configuration.

Implementing Telemetry (capacity, performance metrics)

Telemetry (samples on a direct-attach model) mockup

This mockup shows an example of a small direct attach configuration where the telemetry service is enabled, and showing instrumentation of the Swordfish Capacity Metrics templates.

Service-Based Configuration:
Hosted Service Configuration Mockups

SNIA Swordfish™ Mockups Site
This mockup contains several different systems with different configurations. These are all reflected under the /StorageServices collection.
This mockup set represents a view of what properties are expected to be to be available to vendors to implement, including class of service implemented through underlying lines of service. Note: The mockups do not include accurate representations of the physical components of this system that would normally be represented under the “chassis” hierarchy.

The "Simple1" mockup (./redfish/v1/StorageServices/Simple1/), referred to as the “small mockup”, reflects a small storage system that, while instrumenting class of service, does not have the capability to present the user with class of service controls. It is likely a small external RAID array. This service also demonstrates local replication.

The second mockup, (./redfish/v1/StorageServices/1/), reflects a large enterprise block storage system that presents the user with customized class of service controls as the primary way to configure new block storage. It is likely a large external RAID array, set up in a multi-site DR configuration, with thin-provisioning and other advanced storage configuration features enabled.

The ISC mockup, (./redfish/v1/StorageServices/ISC/), demonstrates a server-attached configuration that instantiates a Storage Service.

The FileService mockup (./redfish/v1/StorageServices/FileService) represents a file server instantiated on top of a block storage system implemented using class of service. Information about the overall file system configuration is in the FileSystem, and individual File Share information is in the FileShare collection.

Implementing Capabilities

NVMe Namespace Creation Capabilities Mockup

This mockup demonstrates usage of Capabilities, showing how capabilities can / should be advertised by implementations.

This example shows some NVMe namespace creation options.

Simple NVMe SSD Mockup

This mockup follows the Swordfish Integrated Configuration model, as the NVM drive is modeled as a PCI attach, so the mockup shows the drive as a PCI-attached drive connected to a system. Note that the drive can also be found by looking in the /Storage collection to find it.

NVMe SSD with Endurance Groups and NVM Sets Mockup

This mockup shares many similarities to the simpler device model, but adds the representation of NVMe Endurance Groups and NVM Sets using the Swordfish StoragePool schema, with additional NVMe specific properties.

JBOF Mockup with NVMe SSDs

SNIA Swordfish™ Mockups Site
This mockup covers a representation of a JBOF ("just a bunch of flash") enclosure and contained drives.

This mockup reflects a PCIe front-end attach configuration with a set of drives.

Ethernet attach Drive with NVMe-of Attach

This mockup reflects an IP-attached drive configuration, with a single ethernet port configured. It includes a drive configured with a default endurance group and NVM Set, and is instantiated in the Storage Collection off the Service Root.The network configuration is modeled in the Chassis.

EBOF Mockup

This mockup covers a representation of a EBOF ("ethernet-attached bunch of flash") enclosure and contained drives. This mockup reflects an Ethernet front-end attach configuration with a set of ethernet-attached drives inside the chassis.

Fabric Attach Array Mockup

The fabric attach array mockup shows a representation where the array exposes native NVMe resources for both front-end and internal components.

Opaque Array (NVMe front end) Mockup

The "opaque" array reflects a system with an NVMe front end, but the internal implementation is vendor specific, and not necessarily presented by the vendor (aka "opaque").This mockup shows a system that presents an NVMe front-end but also exposes a SATA drive backend. This could be done to support both FRU management and volume/namespace creation.

NVMe/TCP Array Mockups

The NVMe/TCP array mockup shows a representation where the array exposes NVM/TCP resources for the front-end interface.

Fabric-attached subsystem Mockup - Ethernet

This mockup shows a logical/exported NVMe-oF connecting via Ethernet, using the Redfish Fabric model. The fabric model uses the Connection schema to characterize the allowed host information, and Endpoints and Zones to show the network connectivity from the device's perspective.

Fabric-attached subsystem - RDMA

This mockup shows a logical/exported NVMe-oF subsystem with connectivity via RDMA. Connectivity and access rights are represented using the Redfish Fabric model. The fabric model uses the Connection schema to characterize the allowed host information, and Endpoints and Zones to show the network connectivity from the device's perspective.

NVMe-oF Discovery Controller Mockups

This mockup presents multiple NVM Subsystems.

One subsystem contains a discovery subsystem, with discovery information about the others.

The other subsystems provide pointers to the subsystem containing the discovery controller.

NVMe Smart Metrics

This mockup shows NVMeSMARTMetrics (.../NVMeSMARTMetrics) on the NVMe IO Controller (/redfish/v1/Systems/Sys-1/Storage/SimplestNVMeSSD/Controllers/NVMeIOController).

The NVMeSMARTMetrics object mirrors the NVMeSMARTMetrics log page.

From an implementation perspective, this metric object can be collected and populated with a single log page call on the device.

NVMe Domains

This mockup features NVMe Domains (/redfish/v1/NVMeDomains).

NVMeDomains contain a collection of domain members; these can be NVM controllers,
endurance groups, NVM sets, or namespaces. Domains can constrain the set of firmware
images available to apply to like members. Other domain-level properties include ALUA
(asymmetric logical unit access) group definitions, indicating common access characteristics and path prioritization behaviors across the namespaces in the domain.
